MITUTOYO SERIES 186 – RADIUS GAGES

MITUTOYO SERIES 186 – RADIUS GAGES

Categories: Dimension, Products

Description
Additional information

• Radius size is stamped on each gage leaf.
• Each leaf comprises an internal and an
external radius gage of the same size.
• With locking clamp.

SPECIFICATIONS

Metric
Code No.	Range (mm)	Accuracy	Composition of leaves	Remarks
186-110	0.4 – 6	±0.04 mm	18 leaves: 0.4, 0.8, 1, 1.2, 1.5, 1.6 mm, 1.75 – 3 mm by 0.25 mm, 3.5 – 6 mm by 0.5 mm	90° arc
186-902	0.5 – 13		26 leaves: 0.5 – 13 mm by 0.5 mm	90° arc, separate part type
186-105	1 – 7		34 leaves: 1 – 3 mm by 0.25 mm, 3.5 – 7 mm by 0.5 mm	180° arc
186-106	7.5 – 15		32 leaves: 7.5 – 15 mm by 0.5 mm	180° arc
186-107	15.5 – 25		30 leaves: 15.5 – 20 mm by 0.5 mm, 21 – 25 mm by 1 mm	180° arc

Inch
Code No.	Range (in)	Accuracy	Composition of leaves	Remarks
186-103	1/32 – 17/64	±0.002 in	16 leaves: 1/32 in – 17/64 in by 64ths	90° arc
186-101	1/32 – 1/4		30 leaves: 1/32 in – 1/4 in by 64ths	180° arc
186-102	17/64 – 1/2		32 leaves: 17/64 in – 1/2 in by 64ths	180° arc
186-104	9/32 – 33/64		16 leaves: 9/32 in – 33/64 in by 64ths	90° arc
186-901*	1/64 – 1/2		25 leaves: 1/64 in – 17/64 in by 64ths, 9/32 in – 1/2 in by 32nds	Holder
186-903	1/64 – 17/64	±0.0016 in	17 leaves: 1/64 in – 17/64 in by 64ths	—
186-904	9/32 – 1/2		8 leaves: 9/32 in – 1/2 in by 32nds	—
186-905	9/16 – 1		8 leaves: 9/16 in – 1 in by 16ths	Holder
186-906	0.010 – 0.500		26 leaves: 0.10 in – 0.30 in by 0.005 in 0.40 in – 0.100 in by 0.010 in 0.120 in – 0.300 in by 0.020 in 0.350 in – 0.500 in by 0.050 in	Holder
186-907	0.550 – 1		10 leaves: 0.550 in – 1 in by 0.50 in	—

Brand	MITUTOYO
