MAHR DIGIMAR 816 CL HEIGHT MEASURING INSTRUMENT

คำอธิบาย
ข้อมูลเพิ่มเติม

Height measuring instrument Digimar 816 CL
Measuring range mm: 0 – 350 mm
0.001 mm, 0.01 mm / 0.00005 inch, 0.0001 inch
Error limit: (2.8+L/300) L in mm
Data interface: Opto RS-232C, USB, wireless
Package contains: height measuring instrument incl. operating and display unit, carrier 817h1, probe K6/51, setting block 817 eb, instruction manual, power source, protection cover, Calibration certificate

Technical data

Measuring range mm	0 – 350 mm
Measuring range	0 – 14″
Resolution	0.001 mm , 0.01 mm
Resolution	0.00005 inch , 0.0001 inch
Error limit	(2.8+L/300) L in mm
Repeatability planes	2 µm
Repeatability bores	3 µm
Perpendicularity error in µm	15 µm
Data interface	Opto RS-232C , USB , wireless
Product weight	25 kg

ยี่ห้อ	Mahr
